Commercial And Home LCD Digital Multimeter Tester Meter

Description (Black & Orange: Multimeter Electrical Test Kit with Voltage Tester Pen and Outlet Socket Tester):

The Kit is an Electrical Test Kit which provides you with basic troubleshooting tools for common electrical problems. This electrical test kit comes with three powerful tools the Manual Ranging CAT II-600V Mini MultiMeter, the Non-Contact Voltage Detector and the Socket Tester. The is a 7-function mini multimeter that measures AC/DC voltage to 600V, DC current to 10A, resistance and diode/continuity on a 2000 count LCD display. The multimeter takes interchangeable test leads and is housed in a durable casing.

The is a Non-Contact Voltage Detector. This NCV detector is for use on 50/60Hz circuits and detects AC Voltage 12V1000V(High Sensitivity) / 48V1000V(Low Sensitivity) without the need to touch the source. Detection is indicated by flashing red LEDs. The Socket Tester is a receptacle tester used to detect faulting wiring in 3 wire receptacles for 5 wiring faults. The Socket Tester utilizes LED lights to indicate good or bad connections.

Measures: Multimeter: AC DC voltage, DC current, resistance, continuity, diode, battery test,

Case Included: Yes, Senses: Outlet tester: open grounds, open neutrals, reversed hot, neutral,

Application: Appliance repair, electrical installation, home inspection.

Features:

Digital Multimeter with large, easy-to-read display measures AC/DC Voltage, DC Current, Resistance, and Continuity and features Diode and Battery tests.

Included Non-Contact Voltage Detector detects AC Voltage 12V1000V(High Sensitivity) / 48V1000V(Low Sensitivity) with a Flashing LED and Audible beeper.

Included Receptacle Tester tests for faulty wiring in 3-wire outlets with a standard North American 3-prong Plug.

Everything you need to stay safe and work smart on DIY home electrical projects.

The KIT includes the Digital Multimeter, Multimeter Test Leads, Non-Contact Voltage Detector,  Receptacle Tester, Storage Case

Non-contact AC Voltage Detector Test Pen Specifications:

Auto Power Off: √

Low battery indication: √

Live/Null Wire Distinguish: Automatically distinguish the Zero line and Fire line with sound (High, Medium,low) and LED light.

NCV Sensitivity: Automatic selection of 3 kinds of sensitivity ( High,Medium,low)  Range of AC Voltage: 48V-1000V/12V-1000V

Frequency: 50Hz / 60Hz

Alarm Mode: Sound and light Flash

Electric Torch: While LED illumination lamp

Auto Power Off: Yes

Low-voltage indicator lamp: Yes

Operating Temperature: 32 to 122F (0 to 50degree)

Storage Temperature: -4 to 140F (-20 to 60degree)

Humidity: < 85%RH

Authentication: CE CAT.III600V RoHS

Battery: 2 * 1.5V AA Batteries (batteries are included)Product Size: 6.1 x 0.8 x 0.8 inches

Security Level: CE CAT. III 1000V / CAT. IV 600V

Service Temperature: 0-40℃

Storage Temperature: -10-50℃

Altitude: <2000m

Digital LCD Multimeter Specification:

15mm high LCD Display.

Max display: 1999, Auto polarity display.

Diode assembly test/Transistor P-N junction test/Transistor HFE test.

Continuity test with buzzer sound in circuit.

Low battery voltage indication.

DC Voltage: 200mV/2V/20V/200V ±0.5%, 600V ±0.8%.

AC Voltage: 200V/600V ±1.2%.

DC Current: 200μA/2mA/20mA ±1%, 200mA ±1.5%, 10A ±3%.

Resistance: 200Ω/2KΩ/20KΩ/200KΩ/2MΩ ±0.8%.

Fuse protection: F-200mA/250V.

Operating Temperature: -0℃ to 40℃.

Over Range Indication: Only figure "1" on the display.

Polarity Indication: "-" displayed for negative polarity.

Low Battery Indication: - /+ display.

Battery: 9V (Battery include).

Dimension: Approx 138mm x 69mm x 31mm.

Socket Tester Wall AC Power Outlet Tester Specification:

Color: Black

Material: Flame Retardant ABS

Plug Type: US

Voltage: 48V-250V 45-65Hz

GFCI Test: 5mA (US Plug)

GFCI Working Voltage: 110V±20V

LED Indicate Condition of the Socket's wiring: Correct connection, Open Ground, Open Neutral, Open Live, LIVE/GRD REVERSE, LIVE/NEU REVERSE,    live/GRD REVERSE,MISSING GRD

Voltage Measurement: 48V250V / 4565Hz

Accuracy: ±(2.0%+2)

Working Environment: 0℃ 40℃, 20% 75%RH

Storage Environment: -10℃ 50℃, 20% 80%RH

Safety Rating: EN61010-1,-2-030, EN61326-1, CAT II 300V

Item Size: 62 * 65 * 55mm / 2.4 * 2.6 * 2.2in

Item Weight: US 53g / 1.9oz

Package Size: 7.5 * 7.4 * 7.3cm / 3.0 * 2.9 * 2.9in

Package Weight: US 79g / 2.8oz

Package Included:

1 x Non-contact Voltage Tester Pen

2 x 1.5V AAA Batteries

1 x Socket Tester(US Adapter)

1 x LCD Digital Multimeter

Note:

1. Due to the light and screen difference, the item's color may be slightly different from the pictures.

2. Please allow 1-2 cm differences due to manual measurement.

Description (Grey & Orange: 2000 Count LCD Multimeter AC DC Voltage Backlit Current Buzzer Voltmeter):

This Multimeter can be used for AC/DC voltage test, DC current test, electric current resistance, hfe (DC amplification) test, two-electrode valve test, NPN PNP transistor test, etc. You can use the Multimeter in more places, such as factory, school lab, home hobby, machine repairing, etc.

Digital LCD multimeter, can be used for Ohm AC/DC volt test and overhaul all kinds of circuit boards Auto polarity display/Diode test/Transistor P-N junction test/Transistor HFE test Auto turn off & Data hold function; Low battery voltage indication Continuity test with buzzer sound in circuit Overload protection on all ranges.

Measurement:

AC/DC Voltage

DC Current

Resistance

Continuity test

Diode assembly test

Transistor P-N junction test

Transistor HFE test

Specification:

DC Voltage:200mV/2V/20V/200V ±0.5%, 600V ±0.8%

AC Voltage:200V/600V ±1.2%

DC Current:200μA/2mA/20mA ±1%, 200mA ±1.5%, 10A ±3%

Resistance:200Ω/2KΩ/20KΩ/200KΩ/2MΩ ±0.8%

Fuse protection:F-200mA/250V

Operating Temperature:-0℃ to 40℃

Over Range Indication-0℃ to 40℃

Over Range Indication:Only figure "1" on the display

Polarity Indication:"-" displayed for negative polarity

Low Battery Indication:- /+ display

Battery:9V (Battery include)

Dimension:Approx 138mm x 69mm x 31mm

Diode assembly test/Transistor P-N junction test/Transistor HFE test.

Continuity test with buzzer sound in circuit.

Low battery voltage indication.

Test Lead Banana Plug to Alligator:

Rated current: 10A

MAX Voltage:CAT.III 600V   CAT.II 1000V

Package included:

1 x LCD Digital Multimeter.

2 x Test Loads.1 x Banana Plug Test Cable.

1 x Orange Back Cover.

1 x English User Manual.

Note:

1. Due to the light and screen difference, the item's color may be slightly different from the pictures.

2. Please allow 1-2 cm differences due to manual measurement.

Description (Digital Multimeter Tester Meter AC DC Volt Current NCV LCD w/ Test Lead):

The 9999counts is a pocket-sized 3 9/10-bit automatic digital instrument. Is a stable performance, high precision, high reliability clear readings, and overload protection . With AAA 1.5V battery-driven, the instrument uses a large-screen LCD display, boost power supply, even in the 2.3V low battery edge, it can guarantee the backlight high brightness, the table is easy to carry, is a vast number of users extremely like the instrument, the backlight can be bright can be automatically turned off after 15 seconds. This series of instruments can be used to measure the DC voltage and AC voltage DC current and AC current, resistance, capacitance diode, continuity test, frequency measurement and true RMS measurement and other parameters. Is an ideal tool for the laboratory, factory, radio enthusiasts and families.

Banana Plug to Alligator Clip Test Lead cables are frequently used in  electrical or laboratory to quickly and cheaply assemble circuits. They are useful for connecting components to wires.

Features:

1. True RMS

2. NCV

3. Auto range

4. 9999 Counts display

5. Black EBTN screen

6.Main measurements: DC/AC/Resistance/Continuity/Diode/Capacitance/Frequency/Temperature

7.Flashlight

8.Backlight

9.Data Hold

10. Auto power off

11. Full unit symbol

12. Max/Min function

13. Relative value measurement

Specification:

Display: Black EBTN screen

Maximum display: 9999 (3 9/10) bits automatic polarity display

Measurement: double integral A / D conversion

Sampling rate: about 3 times per second

Overrange display: the most significant bit was "0L"

Low voltage display: Yes

Working environment: (0~ 40)℃,relative humidity< 80%

Power supply: 2 x AAA 1.5V battery(included)

Volume (size): 142×70×32mm(L×W×H)

Wire Dia: 3.5mm/0.14"

Male Banana Plug Pin Dia: 4mm/0.16"

Alligator Clip Open Width(Max.): 9mm/0.75"

Banana Outer Size: 5.1 x 1cm/2" x 0.4"(L*D)

Alligator Clip Size: 2" x 0.8" x 0.31"(L*W*T)

Total Length: 80cm /2.62ft

Rated current: 15A

MAX Voltage: 1000V

Material: Metal, Plastic

Total Weight: 75g

Package included:

1 x Digital Multimeter Tester Meter

Note:

1. Due to the light and screen difference, the item's color may be slightly different from the pictures.

2. Please allow 1-2 cm differences due to manual measurement.

Illustrate

Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. Please refer to the actual product. The measurement allowed error is +/- 1-3cm.
